QBF-8 12V Dia 0.3" Air Operated Double Diaphragm Pump With Duckbill Valves

Supply Ability
Supply Ability:
5000pcs each day
Packaging & Delivery
Packaging Details
Carton+ white box+ plastic film

Quick Detail:

8L/m air flowrate

18kpa air pressure

Double diaphragm, duckbill valves

Aluminum body

Continuous working day and night

lifetime more than 20,000hours

size:119x87x69 mm

weight:0.60 kg

Outlet & Inlet Dia: 0.3" (7.6 mm)

Description:

CINH AC Dual Diaphragm Air Pump QBF-8 Series use a unique linear motion design that has the capability of over 20,000 hours of continuous maintenance-free operation. They are compact, cool and highly reliable and inexpensive.

Features:

• Compact size
• Steady air outputs with low noise
• Very low vibration
• Low power consumption
• Economical

Specifications:

Air Output: 18SCFH(8Lpm)

Pump Pressure: 2.7PSI(18kpa)

Power Requirement: AC220V,AC120V, AC24V or AC12V, 50Hz or 60Hz

Power Consumption: 7W

Pump Design: Double diaphragm, duckbill valves

Pump Body: Aluminium

Outlet & Inlet Dia: 0.3"(7.6mm)

Electrical Connections: 1-ft(300mm)Insulated wire pair

Noise Level: 40db unconnected, connected operation will reduce db level

Dimension(LxWxH): 119x87x69 mm

Net Weight: 0.60kgs

Performance Curve

Competitive Advantage:

long lifetime, low noise, high quality, 8L/M air flowrate and 18kpa pressure, AC Dual Diaphragm Air Pump

CINH Group Co., Limited is a group limited company, has been engaged in the research and development of micro air pump for more than fifteen years,  With our years of experience of designing and manufacture products, we have been a well-known group company in this industry in China. We have our own professional research institute and several industrial parks and branch  companies in different cities in China, the products have obtained vde, rohs, ce, cb, ul and gs and kema certificates.


We can design and manufacture products according to the customers' special demand. Our products have been exported to many countries, and the amount of products exported to other countries continues to grow, "CINH"  brand will go to worldwide.

Providing you the customer with high quality, professional products and satisfying service is always our attitude; sincerely for ever is our belief; our technology and experience in this industry is our power, we can make it to be reality.

We are fully aware that quality is the life of a company and has a strict quality control system iso from original material sourcing to finished products. We have a special qc team to execute the inspection method of aql level. Realizing that innovation is necessary for continuous development, we have built up an r&d team that is capable of introducing new product lines on a regular basis. This team is also responsible for monitoring the worldwide products market, analyzing consumer trends and making recommendations about how existing lines can be improved. we protect customers" trademarks, and we will never ship trademarked products to the third party or unrelated parties.we accept oem order.

Warmly welcome your inquiry. With high sense of responsibility and absolute sincerity, we welcome all kinds of business cooperation and shall satisfy all needs of our customers. It is our hope to promote, by joint efforts, both trade and friendship tour mutual advantage. Welcome to visit our company and our factory.
If you need more information please contact us at any time. We will be very glad to hear from you soon. Sincerely for ever.
