    Atmospheric Detection Mini Air Pump High Flowrate / Diaphragm Air Pump

    Ask Lasest Price
    Brand Name : Cinh or Neutral
    Certification : CE ROHS UL
    Model Number : QBF-15
    Price : Negotiable
    Delivery Time : 3 to 35days
    Payment Terms : T/T or L/C
    Supply Ability : 5000pcs each day
    • Product Details
    • Company Profile

    Atmospheric Detection Mini Air Pump High Flowrate / Diaphragm Air Pump


    Atmospheric Detection Mini Air Pump High Flowrate / Diaphragm Air Pump


    This air pump is magnetic type working principle, it has two duckvalves, with one piston vibrates from left to right rapidly, to press the two valves to output air. It has obvious advantage is long lifetime, big air flowrate output, no overheat problem and stable and air flowrae; its shortcoming it big size, it can not make same small size as motor air pump.


    Quick Detail:


    Place of Origin:Zhejiang China (Mainland)Brand Name:Cinh or BlankModel Number:QBF-15
    Theory:Electromagnetic PumpStructure:Diaphragm Air PumpUsage:Air Pump
    Power:ElectricFlowrate:15L/mFuel:Electric
    Pressure:30KPAApplication:pressing air

    Specifications:


    ITEMSPECIFICATION
    Air Output:30SCFH(15Lpm)
    Pump Pressure:4.5PSI(30kpa)
    Power Requirement:AC220V,AC120V, AC24V or AC12V, 50Hz or 60Hz
    Power Consumption:10W
    Pump Design:Double diaphragm, duckbill valves
    Pump Body:Aluminium
    Outlet & Inlet Dia:0.3"(7.6mm)
    Electrical Connections:1-ft(300mm)Insulated wire pair
    Noise Level:40db unconnected, connected operation will reduce db level
    Dimension(LxWxH):4.2"x3"x2.9"(106x76x74mm)
    Net Weight:0.62kgs
    Features:Long Life,High Efficiency,Energy Saving

    Applications:


    intermittend pneumatic compression(medical)

    compression therapy

    ozone generator

    aquarium

    recovery system

    fragrance diffuser

    air bed

    Atmospheric Detection

    Dosing chemical material

    air cloth

    medical applications

    industrial applications

    balloon

    medical

    humidifier

    blood pressure

    gas monitor

    dosing

    cooling system

    ink

    water heater

    boiler

    boat

    gas boiler

    breast

    fridge

    pillow and mattress

    beauty equipment


    Performance Curve
